Standard Series
High Efficiency
Reliable Stability
Superior Low-Light Condition Performance
High Efficiency
Using high-performance perovskite thin-film slot-die coating technology, these modules achieve highly uniform large-area deposition. Standard modules reach up to 120 W output, delivering strong, stable performance with high energy conversion efficiency
Reliable Stability
Built with a Double-Glass encapsulation structure and weather-resistant composite materials, the modules offer excellent protection against water, dust, and ageing. After rigorous environmental testing, they maintain long-term stable output
Superior Low-Light Condition Performance
Perovskite modules exhibit outstanding spectral response, enabling high-efficiency power generation under cloudy conditions, at dawn and dusk, and in diffuse light—extending daily power generation time and enhancing overall system yield.
Specifications
General Information
Dimensions - 600 × 1200 mm
Encapsulation Structure - 3.2 PVK + 3.2 T
Thickness - 7 mm
Junction Box Size - 65 × 45 × 13.5 mm
Weight - 12 kg
Electrical Parameters
Rated Power (Pm) - 100 ~ 120 W
Rated Voltage (Vm) - 58 ~ 68 V
Rated Current (Im) - 1.73 ~ 1.77 A
Connector Type - MC4 Connector
Safety & Reliability
Static Load - 2400 Pa
Fire Rating - Class C
Wind Resistance - 1000 Pa
Hail Resistance - 35 mm
Ingress Protection - IP68
